Retinomax Series

Selectable from 4 types.【LCD Type】

  • ・Retinomax Screeen(Only Refraction Measurement Function)
  • ・Retinomax K+Screeen(With Kerato Measurement Function)

【View Finder Type】

  • ・Retinomax 5(Only Refraction Measurement Function)
  • ・Retinomax K-puls5(Only Refraction Measurement Function)

And also selectable from the following 3 kinds of target chart
(Please designate it when you purchase.)



Common Functions
New Function「Focus Assist」
Focus assist function notices you “Just Alignment” with the icon’s color. Blue color indicates the working distance is too far away from the target, otherwise, the red color means being too close to the target. The green color means the distance from the target is OK. This instruments automatically starts measurement when the focus were matched for the stable measurement results.
「New Child Mode」
Child mode helps when measuring Infant’s refraction power with blinking LED varies to four color and Melody. The melody does not stop even though while in the measurement and the Fixation target changes their color to make infants interested in the device.
Improved AX Auto Correction
In the previous model, tilting value were indicated on the screen. The new Retinomax series has function that corrects Cylinderical Axis to tilted direction. An accurate measurement result will be taken with this function.
High Speed Printer
Portable and light. Having Auto Cut function and able to printout in high speed. Connecting PC with USB cable in the market, able to transfer the data though printer took off from the printer but power from PC (But not to printout).
Substantial Memory Function
Bulked up registerable people’s 50(Previous Model) to 60 people.
Original Function
【Retinomax K+Screeen / Retinomax Screeen】
Clear Liquid Crystal Color Monitor
Equipped 3.5inches LCD color monitor with low reflection. It allows to measure with monitoring patient. For the operator does not used to look into View Finder, could be just like “Live View” of Digital Camera.
Tilting LCD with ROM 100°
Incarnated “Comfortable posture and measurement” that everybody requests on the Hand- held refractometer. Adjustable according to the patient’s posture and physical status within 100°.
Light and easy to carry
Decreased the weight from the previous model Centroid is on the grip that feels light when it is carried. And decrease the burden by holding it.

Retinomax3 969g  →  Retinomax Screeen 960g  Decreased 9 grams
Retinomax K-plus3 999g  →  Retinomax K+Screeen 970g  Decreased 29 grams
Improved Battery Life
Adopted Large Capacity battery which able to measure continuously 180 minutes, with no worries about the battery though in the detection survey. Do not have to bring spare battery and measure for 180 minutes (depending on environment and conditions).
【Retinomax K-plus5 / Retinomax 5】
View Finder Model
With view finder observation, no limit operator age. Diopter adjustable range is +/-8D the same as Retinomax3. View finder arm angle is changeable of 0 to 135 degrees. Making measurement easy regardless of patients position or posture.
Easy to carry with light weight
Compare to the previous one, losing decreased the weight huge. Not grasping the grip formally but loading between Thumb and forefinger. Centroid is on the grip and decreases the burden when carrying it long time.

Retinomax3 969g  →  Retinomax 5 940g  Decreased weight 29 grams
Retinomax K-plus3 999g  →  Retinomax K-plus5 950g  Decreased weight 49 grams
Long Life Battery
Adopted Large Capacity battery which able to measure continuously 220 minutes, with no worries about the battery though in the detection survey. Do not have to bring spare battery and measure for 220 minutes (depending on environment and conditions).
